Globe Valves
FLOEC globe valves with on-off, control and parabolic discs for flow regulation, from 150# through 2500# and PN-10 through PN-250.
Overview1 / 4
Trusted Across Process Industries
Valves and engineered equipment from the AB Group supplied to leading oil & gas companies and government undertakings across power, steel and mining.
Product Overview
Smooth-Flow Globe Valves for Regulation and Isolation
We make all varieties of globe valves — on-off disc, control disc and parabolic disc — under the brand name FLOEC, in materials like C.I., S.G. iron, WCB, LCB, WC-1, WC-6, WC-9, CF-8, CF-8M, CF-3, CF-3M, CN-7M, CD4-Cu and Hastelloy. The range runs from 06 NB to 400 NB with pressure ratings from BS/ASME 150# through 2500# and PN-10 through PN-250. Stellite / hard-faced trim is standard on all valves of 600# and higher, and offered on lower ratings on demand.
FLOEC globe valves are designed to guarantee a 100% smooth flow area to decrease pressure drop across the valve. Specifically designed seat and packing materials are offered for superheated steam and high-temperature oils and fluids, so they are easy to service and durable. The valve is accurately machined with a lapped backseat, which allows gland packing to be replaced while the valve is in full stream.
Standard production extends up to 400 NB, and larger sizes, higher pressure ratings and special materials of construction can be customised. Every valve is checked and certified by our Q.C. department, and by clients or any internationally reputed third-party inspection agency.
Typical Applications
- Steam Systems
- Thermal Oil
- Power
- Refineries
- Chemical
- Petrochemical
Globe Valve 900#Key Features
Why Specify FLOEC Globe Valves
Three Disc Types
On-off, control and parabolic discs for isolation or regulation.
Stellite Trim
Stellite / hard-faced trim standard at 600# and above, on demand below.
Lapped Backseat
Gland packing can be replaced while the valve is in full stream.
Steam & Hot Oil
Seat and packing selected for superheated steam and high-temperature fluids.
Smooth Flow Path
Designed for a smooth flow area that reduces pressure drop.
Custom Builds
Larger sizes, higher ratings and special materials on request.
Technical Specification
Globe Valves Data
| Size Range | 50 NB through 400 NB |
|---|---|
| Pressure Rating | BS – 150#, 300#, 400#, 600#, 900#, 1500#, 2500# |
| Type | OS & Y, Bolted / Pressure seal / Seal welded bonnet |
| End Connection | Flanged / Butt weld |
| Operation | Hand wheel / Manual gear / Electric motor actuator |
| Port Opening | Full |
| Seat | Integral / Renewable / Seal welded |
| Disc | Swivel – Flat / Taper / Control / Parabolic |
| Gasket & Packing | PTFE / Graphite / Spiral wound / Ring joint |
| MOC | Refer Material Chart ↓ |
| Design Code | BS 1873, DIN 2401 |
| Testing | BS 6755 Part-I |
| Inspection | 3rd party / Client / Manufacturer |
Material of Construction
FLOEC Material Chart
Standard body, bonnet and trim combinations. Other materials are available on request; 600# and above are supplied with Stellite trim as standard.
| # | Body – Bonnet Material | Trim (Wedge / Seat / Disc) | Stem |
|---|---|---|---|
| 01 | Cast carbon steel ASTM A216 Gr. WCB / WCC | 13% Cr. S.S. | A182 F6 |
| 02 | Cast steel ASTM A352 Gr. LCB and LCC | A351 CF8 | A182 F304 |
| 03 | Low alloy steel ASTM A217 Gr. WC1, WC6, WC9, C12 | 13% Cr. S.S. | A182 F6 |
| 04 | Stainless steel 304 ASTM A351 Gr. CF8 | A351 CF8 | A182 F304 |
| 05 | Stainless steel 304L ASTM A351 Gr. CF3 | S.S. 304L CF3 | A182 F304L |
| 06 | Stainless steel 316 ASTM A351 Gr. CF8M | S.S. 316 CF8M | A182 F316 |
| 07 | Stainless steel 316L ASTM A351 Gr. CF3M | S.S. 316L CF3M | A182 F316L |
| 08 | Alloy 20 ASTM A351 Gr. CN7M | CN7M | UNS N08020 |
| 09 | Duplex SS CD4MCu / CuN / CD3MN | Duplex steel | UNS S32205 |
| 10 | Super duplex A890 Gr. 1A, 1B, 1C, 2A, 3A, 4A, 5A, 6A | Super duplex steel | UNS S32550 |
| 11 | Super alloy steel – Hastelloy Gr. B and C | Hastelloy B/C | Hastelloy B/C |
| 12 | Forged carbon steel – ASTM A105 | 13% Cr. S.S. | A182 F6 |
| 13 | Forged alloy steel – ASTM A182 F11, F22 | 13% Cr. S.S. | A182 F6 |
| 14 | Forged SS A182 F304 / 304L / F316 / 316L | F304/L / F316/L | F304/L / F316/L |
| 15 | SG / Ductile / C.I. of different grades | 13% Cr. SS / CF8 / CF8M | A182 F6 / F304 / F316 |
| 16 | Copper alloys of different grades | Cu. alloys / F304/L / F316/L | Cu. alloys / F304/L / F316/L |
Standards & Testing
Specified to Recognised Codes
Certified & Recognised
Accreditations You Can Verify
FLOEC valves are designed, manufactured and dispatched under an audited quality management system. Select a certificate to view the full document.
ISO 9001:2015Bureau Veritas Certification
Design, manufacture and dispatch of manual, electric and pneumatic operated industrial valves.
NSIC RegistrationThe National Small Industries Corporation
Government Purchase Enlistment Certificate for industrial valve manufacture.
Quality Mark AwardQuality Mark Trust
Certificate of Recognition in the Valve Manufacturers category.
Project Enquiry
Need Help Selecting the Right Valve?
Share operating conditions, line size and media. Our engineering team will assist with globe valves selection, actuation and specification.
