Single Disc Spring Loaded Check Valves
FLOEC single disc spring loaded check valves to DIN 3230, designed to mount between flanges in any direction — ideal for pneumatic, vacuum and instrumentation lines.
Overview1 / 2
Trusted Across Process Industries
Valves and engineered equipment from the AB Group supplied to leading oil & gas companies and government undertakings across power, steel and mining.
Product Overview
Sandwich Check Valves for Instrumentation Lines
The design and manufacture of FLOEC Single Disc Spring Loaded Check Valves is done as per DIN 3230. The valve is designed to mount between flanges of different standards and in whichever direction is needed. It is well suited to instrumentation, especially pneumatic and vacuum applications, as it is offered in both metal-to-metal and soft sealing options.
It is offered in cast iron, S.G. iron, cast carbon steel, and stainless steel of every grade, and in high alloys like Alloy-20, CD4MCu, duplex, super duplex and Hastelloy. Sizes range from 15 NB to 150 NB and pressure ratings from ASME 150# through 2500#.
Typical Applications
- Instrumentation
- Pneumatic Lines
- Vacuum Systems
- Utilities
- Chemical
Key Features
Why Specify FLOEC Single Disc Spring Loaded Check Valves
Any Orientation
Mounts between flanges in whichever direction is needed.
Flange Flexibility
Fits between flanges of different standards.
Instrument Duty
Well suited to pneumatic and vacuum instrumentation lines.
Soft or Metal Seal
Rubber, PTFE or metal-to-metal sealing options.
DIN 3230
Designed to DIN 3230, tested to API 598.
High Pressure Range
ASME 150# through 2500# in 15 to 150 NB.
Technical Specification
Single Disc Spring Loaded Check Valves Data
| Size Range | 15 NB through 150 NB |
|---|---|
| Pressure Rating | ASME – 150#, 300#, 400#, 600#, 900#, 1500#, 2500# |
| Type | Single disc |
| End Connection | Sandwich |
| Operation | Automatic with return pressure |
| Port Opening | Full |
| Seat | Soft – Rubber / PTFE / Metal to metal |
| Disc | Solid disc spring loaded |
| Gasket & Packing | N.A |
| MOC | Refer Material Chart ↓ |
| Design Code | DIN 3230 |
| Testing | API 598 |
| Inspection | 3rd party / Client / Manufacturer |
Material of Construction
FLOEC Material Chart
Standard body, bonnet and trim combinations. Other materials are available on request; 600# and above are supplied with Stellite trim as standard.
| # | Body – Bonnet Material | Trim (Wedge / Seat / Disc) | Stem |
|---|---|---|---|
| 01 | Cast carbon steel ASTM A216 Gr. WCB / WCC | 13% Cr. S.S. | A182 F6 |
| 02 | Cast steel ASTM A352 Gr. LCB and LCC | A351 CF8 | A182 F304 |
| 03 | Low alloy steel ASTM A217 Gr. WC1, WC6, WC9, C12 | 13% Cr. S.S. | A182 F6 |
| 04 | Stainless steel 304 ASTM A351 Gr. CF8 | A351 CF8 | A182 F304 |
| 05 | Stainless steel 304L ASTM A351 Gr. CF3 | S.S. 304L CF3 | A182 F304L |
| 06 | Stainless steel 316 ASTM A351 Gr. CF8M | S.S. 316 CF8M | A182 F316 |
| 07 | Stainless steel 316L ASTM A351 Gr. CF3M | S.S. 316L CF3M | A182 F316L |
| 08 | Alloy 20 ASTM A351 Gr. CN7M | CN7M | UNS N08020 |
| 09 | Duplex SS CD4MCu / CuN / CD3MN | Duplex steel | UNS S32205 |
| 10 | Super duplex A890 Gr. 1A, 1B, 1C, 2A, 3A, 4A, 5A, 6A | Super duplex steel | UNS S32550 |
| 11 | Super alloy steel – Hastelloy Gr. B and C | Hastelloy B/C | Hastelloy B/C |
| 12 | Forged carbon steel – ASTM A105 | 13% Cr. S.S. | A182 F6 |
| 13 | Forged alloy steel – ASTM A182 F11, F22 | 13% Cr. S.S. | A182 F6 |
| 14 | Forged SS A182 F304 / 304L / F316 / 316L | F304/L / F316/L | F304/L / F316/L |
| 15 | SG / Ductile / C.I. of different grades | 13% Cr. SS / CF8 / CF8M | A182 F6 / F304 / F316 |
| 16 | Copper alloys of different grades | Cu. alloys / F304/L / F316/L | Cu. alloys / F304/L / F316/L |
Standards & Testing
